Product Details

Machine Models & Capacity :

• GPSB-3/1000 : 200ML to 1000ML
• GPSB-3/2000 : 200ML to 2000ML

Suitable for Preform Neck :

• 28MM ALASKA
• 28 PCO 1881
• 28 PCO 1810
• 29/21 CTC

Suitable for Segments :

• Packaged Drinking Mineral Water
• Carbonated Soft Drinks
• Hot Fill Juice
• Edible Oil

Salient Features

• GPSB Eco Series Machine – The two-stage process 3 Cavity Stretch Blow Moulding Machine with simple & compact design for Beverage & other applications.
• Telemecanique Schneider PLC & HMI – Controlled by high-performance Schneider Electric Modicon M200 PLC with 4MB SD card memory and rugged construction operated by HMI with TFT 7” colour touch screen, supporting more than 2000 recipes and Ethernet / USB ports for connectivity.
• 40 Ton Toggle Mould Clamping System ensures less than hair parting line in the bottles.
• High Pressure Diaphragm Type Blowing Valve – Highly Efficient High Pressure Diaphragm Type Parker Make Blowing Valve with No Preform No Blow System for reduced Air consumption.
• Direct Preform Transfer Mechanism from Infrared Pre-Heating unit to Blowing unit for reduced Manpower & achieve Maximum Production Output.
• Automatic Bottle Ejection with Gripper Mechanism for reduced Manpower.
• Revolving Infrared Preform heating with Air Circulating System – 1900 MM Two Module 7 Zone Infrared Heating Length with Conveyorized Preheating System to ensures uniform heating of thick wall preforms with less power consumption.
• Preform Pre-heating Conveyor Electrical Type controlled with AC Variable Frequency drive – Bonfiglioli Gear Motor with AC Variable Drive.
• Sensors & Multiple Security Devices are highly sensitive sensors and are provided to ensure safety of the operator as well as the machine.
