Product Details

• FA2C-ABBAX manufactures PET bottles & jars, which are being used for Mineral Water, Edible Oil, Pesticides, Pharmaceuticals, Carbonated Soft Drinks, Liquor, Cosmetics and Confectioneries.
• Production Capacity 1900 to 2000 bottles / hour for 19mm - 30mm neck diameter size.
• Product Capacity 30ml to 2litres.
• Unique Bottle Auto Clipper is used for online filling system and bottle ejection. Machine is equipped with FESTO Cylinders, PARKAR Blowing valves, Yuken Hydraulic Motor Pack and SARIKA - Programmable Logic controller.
• Fully electrical automatic preform loader & 160 character LCD display programmed with two high speed Intel 8051 MICROCONTROLLER are provided for easy operation. Hydraulic clamping with 7.5 HP motor enables adjustment of mould opening dimension according to the product volume.

SPECIFICATION	UNIT	FA2C-ABBAX
Product Capacity	ml	60 to 2000
Neck Dia	mm	19 to 30
Max. Product Dia	mm	100
Max. Product Height	mm	340
Production Capacity	Bottle/Hr	1900 to 2000
Max. Blow Height	mm	340
Cavity	no	2
Operating Pressure	Kg	8 to 9
Blowing Pressure	Kg	25 - 32
Heater Power	Kw	24
Clamping Stroke	mm	200
Clamping Force	ton	20
Max.Mould Thickness	mm	200
Min.Mould Thickness	mm	150
Cavity Centre Distance	mm	130
Air Requirement	cfm	80 - 100

“ In our endeavor to improve quality, product specifications and look may change without prior notice”
