Product Details

Type	Fully Automatic
Power	2 - 2.5kw
Condition	New
Tray Size	10 Inches
Electrical Power	53 Kw
Compressed Air	6 - 8 Bar
Space Requirement	4m Width X 13m Length
Chamber Heater	36 Kw
Chamber Conveyor	2 Hp
Preferred Buyer From	Anywhere in India

Capacity :

30ml to 2 ltr, Neck dia 25mm to 28mm

Prod. Capacity :

2000-2200 BPH

Mould :

• Maximum mould thickness-150mm
• Minimum mould thickness -140mm
• Clamping Force- 15 ton

Oven :

• Number of Preform Holders - 67
• Number of Heating Modules - 1
• Number of Heating Zones - 6
• Lamp Power - 2000 W
• Lamp Length - 1120mm

Stretching :

• Number of Stretch Rods - 4
• Stretching Stroke Max. - 450 mm

Technical specifications :

• Infrared pre-heating system
• Chain Conveyor similar to fully AUTOMATIC machine
• Steady perform rotating in pre-heater
• Janatics pneumatic system & water cooling system
• Hydro-pneumatic Locking systems with operating manual
